Mini crawler dumper Weima WM7B-750

Sand? Garden waste? Bulk material? – No problem! The mini crawler dumper Weima WM7B-750 will make your life easier. The WM7B-750 is a versatile machine used for carrying various loads of any shape and size, weighing up to 750 kg. The device is equipped with a Weima WM170F petrol engine, which ensures reliable and efficient operation. The belt clutch makes the design easy to maintain, and the four-speed gearbox simplifies choosing the optimal speed for work. The loading area can be enlarged by opening the sides. The Weima WM7B-750 stands out for its agility and high productivity, and the tipping container greatly eases the unloading process. The crawler dumper will be your helper in the garden, greenhouse, farm, or on the building site.

• GTIN: 6971472300964
• Tipping container: 1190 × 760 × 200 mm
• Tipping mechanism: Mechanical (up to 50°)
• Maximum load capacity: up to 750 kg
• Climbing ability: 25° (without load)
• Drive: Gear drive
• Gear shift: 3 forward, 1 reverse
• Minimum turning radius: 2.5 m
• Gear oil capacity: 3.5 L
• Net weight: 270 kg
• Dimensions: 2050 x 900 x 1200 mm
Engine
• Engine model: Weima WM170F
• Type: EURO 5, OHV, single-cylinder, 4-stroke, forced cooling
• Displacement: 212 cm³
• Max. engine power: 5 kW / 7 hp
• Starting system: Pull starter
• Fuel volume: 3.6 L
• Engine oil volume: 0.6 L
• Fuel consumption: 395 g / kW∙h

• Mini crawler dumper Weima WM7B-750
• 1 × key set
• 1 × user manual
• 2 years warranty

Manufacturer/EU Responsible Person

EU Responsible Person

Company name:
Grünwelt Maschinen GmbH

Address:
Halberstädterstr. 115
39112, Magdeburg
Saxony-Anhalt
Germany

E-Mail: office.gruenwelt@gmail.com
Phone: +49 15731450718

• Not suitable for children under 3 years.
• Caution: Please keep out of reach of children.
• Caution: Use only with device protection. Do not use on public roads.
