Power generator Weima WM3200BE

The gasoline power generator Weima WM3200BE is based on a single-cylinder engine Weima WM170FE, which is equipped with an electric starter and cooled by an effective air cooling system. The open design on a sturdy frame offers maximum lightness, mobility, and easy access to the working parts for necessary maintenance or repair. Additionally, the generator is equipped with a 12V outlet and an integrated V.F.T. digital meter that displays the operating voltage, operating frequency, as well as both the current usage time and the continuous usage time for maintenance purposes. The automatic voltage regulator (AVR) delivers high-quality voltage to supply even sensitive devices with power. The Weima WM3200BE device is used in household and semi-professional settings, in the garage, in workshops, as well as during outdoor recreation, to supply various single-phase devices, electric tools, and other equipment with power.

• GTIN: 4260614712089
• Type of generator: single-phase synchronous generator
• Maximum power: 3200 W
• Continuous power: 2800 W
• Output voltage: 220 V
• Rated frequency: 50 Hz
• Connections: 2 × AC 220 V
• Direct current output: 12 V / 8.3 A
• Running time at 2/3 load: approx. 6 hours
• Protection class: IP 23
• Sound power level Lwa: 77 dB(A)
• Dimensions: 601 × 436 × 470 mm
• Dry weight: 45 kg
• Engine model: Weima WM170FE
• Type: 4-stroke, forced cooling, single cylinder, overhead valve, electric starter
• Displacement: 212 cm³
• Bore × stroke: 70 × 55 mm
• Engine power: 5 kW / 7 hp at 3,600 rpm
• Fuel capacity: 16 L
• Engine oil capacity: 0.6 L
• Fuel consumption: 313 g/kW∙h

Manufacturer/EU Responsible Person

EU Responsible Person

Company name:
Grünwelt Maschinen GmbH

Address:
Halberstädterstr. 115
39112, Magdeburg
Saxony-Anhalt
Germany

E-Mail: office.gruenwelt@gmail.com
Phone: +49 15731450718

• Not suitable for children under 3 years.
• Caution: Please keep out of reach of children.
• Caution: Use only with device protection. Do not use on public roads.
