Mini crawler dumper Grünwelt GW-B750BH (Diesel, electric starter and standing platform)

Sand? Garden waste? Bulk material? – No problem! The mini crawler dumper Grünwelt GW-B750ВH will make your life easier. The hydraulic lifting system of the tipping container makes work easier than ever before! The Grünwelt GW-B750ВH is a versatile unit used for transporting various loads of any shape and size, weighing up to 750 kg. Flat surface: Load capacity up to 750 kg. Slope of 17% or 10 degrees: Load capacity up to 600 kg. Slope of 30% or 17 degrees: Load capacity up to 375 kg. The device is equipped with a petrol engine that ensures reliable and efficient operation. The belt clutch makes the design easy to maintain, and the four-speed gearbox facilitates selecting the optimal speed for operation. The loading area can be enlarged by opening the sides. The Grünwelt GW-B750ВH stands out for its maneuverability and high productivity, and the tipping container greatly simplifies the unloading process. The crawler dumper will be your helper in the garden, greenhouse, farm, or construction site. A special feature of the Grünwelt GW-B750ВH is the standing platform, which allows the operator an ergonomic working position while also simplifying transport.

• GTIN: 4260614713338
• Tipping container: 1190 x 760 x 200 mm
• Tipping mechanism: Hydraulic (up to 50°)
• Maximum load capacity: up to 750 kg
• Climbing ability: 25° (unloaded)
• Drive: Gear drive
• Gear shift: 3 forward, 1 reverse
• Minimum turning radius: 2.5 m
• Gear oil capacity: 3.5 L
• Net weight: 290 kg
• Dimensions: 1550 x 1100 x 1275 mm
Engine
• Engine model: WM178FE
• Type: Single-cylinder, 4-stroke, forced cooling
• Displacement: 296 cm³
• Maximum engine power: 4.4 kW / 6 hp at 3600 rpm
• Starting system: Pull starter, electric starter
• Fuel / engine oil volume: 3.5 / 1.1 L

• Mini crawler dumper Grünwelt GW-B750BH
• 1 × key set
• 1 × user manual
• 2 years warranty
